Blodgett DFG50 Gas Double Deck Convection Oven

Blodgett DFG50 Gas Double Deck Convection Oven

EXTERIOR CONSTRUCTION:

• Full angle-iron frame
• Stainless steel front, top, sides, and back
• Dual pane thermal glass window encased in the stainless steel door frame
• Single chrome plated door handle
• Tilt-down modular front control panel
• Solid mineral fiber insulation at the top, back, sides, and bottom

INTERIOR CONSTRUCTION:

• Double-sided porcelainized baking compartment liner (14 gauge)
• Aluminized steel combustion chamber
• Dual inlet blower wheel
• Five chrome-plated racks, nine rack positions with a minimum of 15/8” (41mm) spacing

OPERATION:

• Dual Flow Gas system combines direct and indirect heat
• Electronic spark ignition control system
• Removable dual tube burner
• Pressure regulator and manual gas service cut-off valve located in the front control area
• Air mixers with adjustable air shutters
• Solid state thermostat with a temperature control range of 200°F (93°C) to 500°F (260°C)
• Single speed fan motor
• 1/2 horsepower blower motor with automatic thermal overload protection
• One control area cooling fan

STANDARD FEATURES:

• 27,000 BTU/hour per section
• Dual Flow Gas system combines direct and indirect heat
• 1/3 HP convection motor w/automatic thermal overload protection
• Warranty: 2-year parts, 1-year labor
• 5-year limited warranty on doors
• Capacity – up to 5 half-size baking pans in front to back position
